In line helical gear reducers

One, two and three-stage reduction coaxial reducers.

VARMEC gearboxes and motors have been designed entirely with the help of computer-based technical programs. Each individual component has been tested and manufactured taking into account the maximum load applicable to the gearbox according to AGMA 2001-B88.

The main design features are:

• Modularity

• Compactness
• Universal fittings
• High yields
• Low noise level
• Hardened and hardened alloy steel gears

Unpainted aluminium cases in sizes 141 - 191 - 162 - 202A - 252A - 253A - 302A - 303A, high strength cast iron cases painted in other sizes

• High-strength steel input and output shafts


Construction characteristics

The machining of the various components takes place on modern CNC machining centers that allow to obtain the maximum precision. All the gears are machined with teeth grinding to improve their performance and quiet operation, even under load.

I riduttori VARMEC sono disponibili in 5 grandezze per i tipi ad uno stadio di riduzione (141 – 191 – 241 – 281 – 381) e in 12 grandezze per i tipi a 2 e 3 stadi di riduzione (162 – 202A – 200 – 250A – 250 – 300A – 300 – 350 – 450 – 550 – 580 – 600).

• Applicable powers from 0.09 to 54 kW 4 poles

• Torques from 15 to 3500 Nm
• Reduction ratios from 1:1.14 to 1:372
